Understanding Design Parking Lot in Java

Designing a Parking Lot is one of the most common Object-Oriented Design (OOD) questions asked during software engineering interviews. It evaluates a candidate's ability to take a complex physical system and break it down into clean, maintainable software abstractions. Doing this successfully requires applying core object-oriented programming (OOP) principles: Inheritance, Encapsulation, and Polymorphism.

A functional parking lot system needs to model several entities:

• Vehicles: Supporting distinct types like Bikes, Cars, and Trucks.
• Parking Spots: Matching different vehicle sizes and enforcing size constraints (e.g., a Truck cannot fit into a Bike spot).
• Parking Coordinator: A manager class that allocates available spots to incoming vehicles and frees them when vehicles depart.

Design Strategy

We structure our Java solution around three fundamental OOD strategies:

• Polymorphic Hierarchy: We define an abstract Vehicle base class. Concrete vehicle subclasses (like Car or Bike) inherit from it and specify their default type. This keeps the design open for extension.
• Encapsulation of State: Each ParkingSpot manages its own state (isFree, parkedVehicle). It exposes a park(Vehicle) method that evaluates its own validation rules internally rather than letting external classes modify its fields.
• Delegation of Responsibility: The ParkingLot coordinator class contains a collection of spots. When a vehicle arrives, the coordinator iterates through the spots, delegating the parking decision to each spot until one successfully accepts the vehicle.

Step-by-Step Execution Walkthrough

Let's trace this flow with a parking lot containing a single empty CAR spot:

1. Vehicle Arrival: A Car object (license "MH12-1234") arrives. We call lot.parkVehicle(car).
2. Constraint Check: The loop inspects the spots. It invokes spot1.park(car). The spot checks if it is free and if its spot type (CAR) matches the vehicle type (CAR). Since both conditions are true, the spot is marked occupied, and the operation returns success.
3. Subsequent Request: A second car arrives. We call lot.parkVehicle(car2). The coordinator checks spot1, but spot1.park(car2) returns failure because the spot is already occupied.
4. Vehicle Departure: The first car leaves. We call lot.unparkVehicle(car). The coordinator searches the spots, finds the spot holding the car, and calls spot1.leave(), resetting the spot's state to free.

Key Code Explanations

Here is why the main logic in the solution is important:

• public abstract static class Vehicle: Enforces inheritance. By declaring this abstract, we ensure no generic "Vehicle" can be instantiated directly; it must be a concrete type like Car or Bike.
• if (isFree && v.type == type): Enforces type-safety. Prevents a Truck from parking in a Motorcycle spot.
• s.park(v): The delegation step. The lot itself doesn't modify the spot's attributes directly; it requests the spot to execute the action, respecting encapsulation.

Java Implementation Code

Below is the complete, self-contained Java source code that solves this problem. It also includes a main method that traces the execution with console outputs.

package io.practise.dsa;

import java.util.*;

public class DesignParkingLot {

    // Enum representing supported vehicle/spot sizes
    public enum VehicleType {
        BIKE,
        CAR,
        TRUCK
    }

    // Abstract base class representing a generic vehicle
    public abstract static class Vehicle {
        VehicleType type;
        String license;

        public Vehicle(VehicleType type, String license) {
            this.type = type;
            this.license = license;
        }
    }

    // Concrete Car class inheriting from Vehicle
    public static class Car extends Vehicle {
        public Car(String license) {
            super(VehicleType.CAR, license);
        }
    }

    // Class representing a single parking spot
    public static class ParkingSpot {
        private final VehicleType type;
        private boolean isFree;
        private Vehicle vehicle;

        public ParkingSpot(VehicleType type) {
            this.type = type;
            this.isFree = true;
        }

        // Park the vehicle if spot is free and type matches
        public boolean park(Vehicle v) {
            if (isFree && v.type == this.type) {
                this.vehicle = v;
                this.isFree = false;
                return true;
            }
            return false;
        }

        // Vacate the spot
        public void leave() {
            this.vehicle = null;
            this.isFree = true;
        }

        public boolean isFree() {
            return isFree;
        }

        public Vehicle getVehicle() {
            return vehicle;
        }
    }

    // Controller class managing multiple spots
    public static class ParkingLot {
        private final List<ParkingSpot> spots;

        public ParkingLot(List<ParkingSpot> spots) {
            this.spots = spots;
        }

        // Scan and park in the first available slot
        public boolean parkVehicle(Vehicle v) {
            for (ParkingSpot s : spots) {
                if (s.park(v)) {
                    return true;
                }
            }
            return false;
        }

        // Scan and vacate the spot holding the vehicle
        public void unparkVehicle(Vehicle v) {
            for (ParkingSpot s : spots) {
                if (s.getVehicle() == v) {
                    s.leave();
                    break;
                }
            }
        }
    }

    public static void main(String[] args) {
        System.out.println("--- Design Parking Lot Demonstration ---");

        ParkingSpot spot1 = new ParkingSpot(VehicleType.CAR);
        ParkingLot lot = new ParkingLot(List.of(spot1));

        Car car = new Car("MH12-1234");

        System.out.println("Attempting to park Car [MH12-1234]...");
        boolean park1 = lot.parkVehicle(car);
        System.out.println("Parking Success: " + park1 + " (Expected: true)");

        System.out.println("\nAttempting to park same Car again (no empty spots)...");
        boolean park2 = lot.parkVehicle(car);
        System.out.println("Parking Success: " + park2 + " (Expected: false)");

        System.out.println("\nCar vacating spot...");
        lot.unparkVehicle(car);
        System.out.println("Spot status isFree: " + spot1.isFree() + " (Expected: true)");
    }
}

Conclusion & Practical Takeaways

Distributing system logic into distinct, specialized classes (Vehicle subclasses, ParkingSpot verifiers, and ParkingLot coordinators) makes the codebase highly modular. This encapsulation ensures that if we decide to add new vehicle types, such as Electric Vehicles with charging stations, we can extend the system with minimal modifications to existing code.
